Introduction

The AQL-913 is a 100W RGBW LED floodlight designed for general-purpose illumination in a range of scenarios. Available in multiple optical beams and treated with an enhanced thermal dissipation paint.



Specification

AQL-913

AQL-900 Series

CNC Machined Aluminium

3 Year Aqualux Warranty

IP65

AQL-913 Datasheet

Options

Body

  • Black Powder Coat (Al)

    Aluminium 6000 Series

Control Gear

  • 24V DC

    Dimming: PWM Power Dimming

Light Sources

  • 100W / 5550lm

    RGB+3000K

Optical

  • Wide (50°)

    50

  • Flood (70°)

    70

  • Medium (30°)

    30

Cable

  • S

    1m Aqualux Cable

Configure order code

AQL-913

To configure your product/s, select from the options below.
Multiple selections are possible to produce your downloadable datasheet/s.

AQL-913 - You have 3 variations with this product

Product Code Downloads Body Rated Power Light Source Optical Control Gear Dimming Cable Downloads
AQL-913-BK-E100Z250S
Black Powder Coat (Al)
Aluminium 6000 Series
100W 5550lm / RGB+3000K 50 24V DC PWM Power Dimming 1m Aqualux Cable
AQL-913-BK-E100Z270S
Black Powder Coat (Al)
Aluminium 6000 Series
100W 5550lm / RGB+3000K 70 24V DC PWM Power Dimming 1m Aqualux Cable
AQL-913-BK-E100Z230S
Black Powder Coat (Al)
Aluminium 6000 Series
100W 5550lm / RGB+3000K 30 24V DC PWM Power Dimming 1m Aqualux Cable

Aqualux is introducing an updated product code structure throughout 2020. Quotes, invoices and other documents may reference the previous product code structure until we have completed this update.
