Introduction

The AQL-602 is an elegant square wall light for high lighting columns and other architectural elements. Featuring a 7W 3000K CREE LED and a soft falloff 70D optic, it also comes with a removable slotted gobo for creating a dramatic slit effect.



Specification

AQL-602

Elements

Cast Aluminium & Powder Coat

Terminal Block

3 Year Aqualux Warranty

IP65

Comes with a removable gobo for dramatic lighting of columns

Options

Body

  • Matt Black

    Aluminium 6000 Series

Control Gear

  • 24V DC

    Dimming: PWM 10V Dimming

  • 240V

    Dimming: No

Light Sources

  • 7W / 615lm

    3000K / 700mA

Optical

  • Flood (70°)

    70

Cable

  • T

    Terminal Block

Configure order code

AQL-602

To configure your product/s, select from the options below.
Multiple selections are possible to produce your downloadable datasheet/s.

AQL-602 - You have 2 variations with this product

Product Code Downloads Body Rated Power Light Source Optical Control Gear Dimming Cable Downloads
AQL-602-BK-B0073070T
Matt Black
Aluminium 6000 Series
7W 615lm / 3000K / 700mA 70 24V DC PWM 10V Dimming Terminal Block
AQL-602-BK-F0073070T
Matt Black
Aluminium 6000 Series
7W 615lm / 3000K / 700mA 70 240V No Terminal Block

Aqualux is introducing an updated product code structure throughout 2020. Quotes, invoices and other documents may reference the previous product code structure until we have completed this update.
