Introduction

A prism shaped wall light featuring dual up/down light throw and a 70 degree optic



Specification

AQL-601

Elements

Cast Aluminium & Powder Coat

Terminal Block

3 Year Aqualux Warranty

IP65

Options

Body

  • Matt Black

    Aluminium 6000 Series

  • White (Al)

    Aluminium 6000 Series

Control Gear

  • 24V DC

    Dimming: PWM 10V Dimming

  • 240V

    Dimming: No

Light Sources

  • 14W / 1230lm

    3000K / 700mA

Optical

  • Flood (70°)

    70

Cable

  • T

    Terminal Block

Configure order code

AQL-601

To configure your product/s, select from the options below.
Multiple selections are possible to produce your downloadable datasheet/s.

AQL-601 - You have 4 variations with this product

Product Code Downloads Body Rated Power Light Source Optical Control Gear Dimming Cable Downloads
AQL-601-BK-B0143070T
Matt Black
Aluminium 6000 Series
14W 1230lm / 3000K / 700mA 70 24V DC PWM 10V Dimming Terminal Block
AQL-601-BK-F0133070T
Matt Black
Aluminium 6000 Series
14W 1230lm / 3000K / 700mA 70 240V No Terminal Block
AQL-601-WH-B0143070T
White (Al)
Aluminium 6000 Series
14W 1230lm / 3000K / 700mA 70 24V DC PWM 10V Dimming Terminal Block
AQL-601-WH-F0133070T
White (Al)
Aluminium 6000 Series
14W 1230lm / 3000K / 700mA 70 240V No Terminal Block

Aqualux is introducing an updated product code structure throughout 2020. Quotes, invoices and other documents may reference the previous product code structure until we have completed this update.
