Introduction

High Powered spike uplight. 20W LED



Specification

AQL-132

Lumena

CNC Machined & Anodised Aluminium 6061, CNC Machined Aluminium

1M Aqualux PLUS QuickConnect

5 Year Aqualux Warranty

IP67

Options

Body

  • Satin Chrome Anodize

    Aluminium 6000 Series

  • Black Ace

    Aluminium 6000 Series

  • Medium Bronze

    Aluminium 6000 Series

  • Venerable Silver

    Aluminium 6000 Series

Control Gear

  • 24V DC

    Dimming: PWM 10V Dimming

Light Sources

  • 20W / 2050lm

    3000K / 1000mA

Optical

  • Medium (25°)

    25

  • Wide (38°)

    38

  • Narrow (15°)

    15

Cable

  • Q

    AqualuxPLUS QuickConnect

Configure order code

AQL-132

To configure your product/s, select from the options below.
Multiple selections are possible to produce your downloadable datasheet/s.

AQL-132 - You have 12 variations with this product

Product Code Downloads Body Rated Power Light Source Optical Control Gear Dimming Cable Downloads
AQL-132-A1-B0203025Q
Satin Chrome Anodize
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 25 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A1-B0203038Q
Satin Chrome Anodize
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 38 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A1-B0203015Q
Satin Chrome Anodize
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 15 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A2-B0203025Q
Black Ace
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 25 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A2-B0203038Q
Black Ace
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 38 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A2-B0203015Q
Black Ace
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 15 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A3-B0203025Q
Medium Bronze
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 25 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A3-B0203038Q
Medium Bronze
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 38 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A3-B0203015Q
Medium Bronze
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 15 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A4-B0203025Q
Venerable Silver
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 25 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A4-B0203038Q
Venerable Silver
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 38 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect
AQL-132-A4-B0203015Q
Venerable Silver
Aluminium 6000 Series
20W 2050lm / 3000K / 1000mA 15 24V DC PWM 10V Dimming AqualuxPLUS QuickConnect

Aqualux is introducing an updated product code structure throughout 2020. Quotes, invoices and other documents may reference the previous product code structure until we have completed this update.
