AQS and AQF quick reference guide

    All the AQS and AQF products are listed below for a quick reference comparison.

    AQS-170 - COB Strip

    IP20  -  24V DC
    Vertical bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    10mm Wide x 1.6mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-170-27A5 2700K 24V DC 5W 482lm 80 31.25mm 5M
    AQS-170-30A5 3000K 24V DC 5W 519lm 80 31.25mm 5M
    AQS-170-40A5 4000K 24V DC 5W 575lm 80 31.25mm 5M
    AQS-170-50A5 5000K 24V DC 5W 600lm 80 31.25mm 5M
    AQS-170-27A10 2700K 24V DC 10W 957lm 80 31.25mm 5M
    AQS-170-30A10 3000K 24V DC 10W 1029lm 80 31.25mm 5M
    AQS-170-40A10 4000K 24V DC 10W 1138lm 80 31.25mm 5M
    AQS-170-50A10 5000K 24V DC 10W 1200lm 80 31.25mm 5M
    AQS-170-20A15 2000K 24V DC 15W 1200lm 80 31.25mm 5M
    AQS-170-27A15 2700K 24V DC 15W 1418lm 80 31.25mm 5M
    AQS-170-30A15 3000K 24V DC 15W 1527lm 80 31.25mm 5M
    AQS-170-40A15 4000K 24V DC 15W 1690lm 80 31.25mm 5M
    AQS-170-50A15 5000K 24V DC 15W 1750lm 80 31.25mm 5M

    AQS-172 - COB Strip

    IP20  -  24V DC
    Vertical bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    4mm Wide x 2mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-172-20A05 2000K 24V DC 5W 400lm 80 31.25mm 5M
    AQS-172-30A05 2700K 24V DC 5W 507lm 80 31.25mm 5M
    AQS-172-40A05 3000K 24V DC 5W 520lm 80 31.25mm 5M
    AQS-172-50A05 4000K 24V DC 5W 565lm 80 31.25mm 5M
    AQS-172-27A10 6500K 24V DC 5W 580lm 80 31.25mm 5M

    AQS-173-Mono - COB Strip

    IP20  -  24V DC
    Vertical bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    12mm Wide x 2mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-173-20A5 2000K 24V DC 20W 1140lm 80 27.78mm 5M
    AQS-173-27A5 2700K 24V DC 20W 1420lm 80 27.78mm 5M
    AQS-173-30A5 3000K 24V DC 20W 1633lm 80 27.78mm 5M
    AQS-173-40A5 4000K 24V DC 20W 1740lm 80 27.78mm 5M

    AQS-173-RGBW - COB Strip

    IP20  -  24V DC
    Vertical bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    10mm Wide x 1.6mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-173-Z2A16 RGB + 3000K 24V DC 16W 465lm - 630lm 80 50mm 5M

    AQS-180 - Ultra

    IP20  -  24V DC
    Vertical bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    10mm Wide x 2mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-180-20A20 2000K 24V DC 20W 2220lm 90+ 29.4mm 5M
    AQS-180-27A20 2700K 24V DC 20W 2587lm 90+ 29.4mm 5M
    AQS-180-30A20 3000K 24V DC 20W 2954lm 90+ 29.4mm 5M
    AQS-180-40A20 4000K 24V DC 20W 3320lm 90+ 29.4mm 5M

    AQS-400 Neon Flex

    IP65  -  24V DC
    Vertical bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    10mm Wide x 9mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-400-20A10 2000K 24V DC 10W 400lm 90 31mm 5M
    AQS-400-27A05 2700K 24V DC 5W 260lm 90 31mm 7M
    AQS-400-30A05 3000K 24V DC 5W 270lm 90 31mm 5M
    AQS-400-27A10 2700K 24V DC 10W 500lm 90 31mm 7M
    AQS-400-30A10 3000K 24V DC 10W 530lm 90 31mm 5M
    AQS-400-40A10 4000K 24V DC 10W 540lm 90 31mm 5M
    AQS-400-50A10 5000K 24V DC 10W 545lm 90 31mm 5M

    AQS-401 Neon Flex

    IP65  -  24V DC
    Vertical bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    10mm Wide x 10mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-401-20A10 2000K 24V DC 10W 320lm 90 35.7mm 5M
    AQS-401-27A05 2700K 24V DC 5W 380lm 90 35.7mm 7M
    AQS-401-27A10 2700K 24V DC 10W 730lm 90 35.7mm 5M
    AQS-401-30A10 3000K 24V DC 5W 400lm 90 35.7mm 7M
    AQS-401-30A10 3000K 24V DC 10W 780lm 90 35.7mm 5M
    AQS-401-40A10 4000K 24V DC 10W 820lm 90 35.7mm 5M
    AQS-401-50A10 5000K 24V DC 10W 830lm 90 35.7mm 5M

    AQS-402 Neon Flex

    IP65  -  24V DC
    Horizontal bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    6mm Wide x 12mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-402-20A10 2000K 24V DC 10W 250lm 90 50mm 5M
    AQS-402-27A05 2700K 24V DC 5W 180lm 90 50mm 7M
    AQS-402-27A10 2700K 24V DC 10W 360lm 90 50mm 5M
    AQS-402-30A05 3000K 24V DC 5W 160lm 90 50mm 7M
    AQS-402-30A10 3000K 24V DC 10W 310lm 90 50mm 5M
    AQS-402-40A10 4000K 24V DC 10W 365lm 90 50mm 5M
    AQS-402-50A10 5000K 24V DC 10W 400lm 90 50mm 5M
    AQS-402-Z1A10 RGB 24V DC 10W 126lm - 50mm 5M

    AQS-410 Neon Flex

    IP65  -  24V DC
    Vertical bending  -  Emission Angle 180°
    3-year Aqualux Warranty
    13mm Wide x 12mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-410-Z1A10 RGB 24V DC 10W 580lm - 55.5mm 5M

    AQS-420 Neon Flex

    IP65  -  24V DC
    Horizontal bending  -  Emission Angle 120°
    3-year Aqualux Warranty
    12mm Wide x 20mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-420-20A10 2000K 24V DC 10W 270lm 90 50mm 5M
    AQS-420-27A10 2700K 24V DC 10W 300lm 90 50mm 5M
    AQS-420-30A10 3000K 24V DC 10W 330lm 90 50mm 5M
    AQS-420-40A10 4000K 24V DC 10W 340lm 90 50mm 5M
    AQS-420-50A10 5000K 24V DC 10W 345lm 90 50mm 5M
    AQS-420-20A15 2000K 24V DC 15W 450lm 90 50mm 5M
    AQS-420-27A15 2700K 24V DC 15W 460lm 90 50mm 5M
    AQS-420-27A15 3000K 24V DC 15W 470lm 90 50mm 5M
    AQS-420-27A15 4000K 24V DC 15W 500lm 90 50mm 5M
    AQS-420-50A15 2700K 24V DC 15W 525lm 90 50mm 5M
    AQS-420-Z2A15 RGB+3000K 24V DC 15W 300lm 80 71.4mm 5M

    AQS-421 Neon Flex

    IP65  -  24V DC
    Horizontal bending  -  Emission Angle 120°
    3-year Aqualux Warranty
    16mm Wide x 15mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-421-20A15 2000K 24V DC 15W 680lm 90 50mm 5M
    AQS-421-27A15 2700K 24V DC 15W 770lm 90 50mm 5M
    AQS-421-30A15 3000K 24V DC 15W 850lm 90 50mm 5M
    AQS-421-40A15 4000K 24V DC 15W 915lm 90 50mm 5M
    AQS-421-50A15 5000K 24V DC 15W 930lm 90 50mm 5M
    AQS-421-Z2A15 RGB + 3000K 24V DC 15W - - 63mm 5M

    AQS-500 Neon Flex

    IP68  -  24V DC
    Horizontal bending  -  Emission Angle 120°
    3-year Aqualux Warranty
    11.5mm Wide x 21mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-500-27A12 2700K 24V DC 12W 150lm 80 100mm 10M
    AQS-500-30A12 3000K 24V DC 12W 340lm 80 100mm 10M
    AQS-500-40A12 4000K 24V DC 12W 360lm 80 100mm 10M
    AQS-500-50A12 5000K 24V DC 12W 370lm 80 100mm 10M
    AQS-500-65A12 6500K 24V DC 12W 320lm 80 100mm 10M
    AQS-500-Z1A12 RGB 24V DC 12W ??? 80 100mm 10M
    AQS-500-Z3A17 RGB + 2700K 24V DC 17W ??? 80 100mm 8M
    AQS-500-Z2A17 RGB + 3000K 24V DC 17W ??? 80 100mm 8M
    AQS-500-Z0A17 RGB + 4000K 24V DC 17W ??? 80 100mm 8M
    AQS-500-Z4A17 RGB + 6500K 24V DC 17W ??? 80 100mm 8M
    AQS-500-Z6A18 RGB 24V DC 18W ??? 80 100mm 8M

    AQS-505 Neon Flex

    IP68  -  24V DC
    Vertical bending  -  Emission Angle 120°
    3-year Aqualux Warranty
    12mm Wide x 20mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-505-RDA10 Red 24V DC 10W 175lm 80 83.3mm 10M
    AQS-505-GNA10 Green 24V DC 10W 529lm 80 83.3mm 10M
    AQS-505-BUA10 Blue 24V DC 10W 721lm 80 83.3mm 10M
    AQS-505-22A10 2200K 24V DC 10W 430lm 80 83.3mm 10M
    AQS-505-27A10 2700K 24V DC 10W 435lm 80 83.3mm 10M
    AQS-505-30A15 3000K 24V DC 10W 450lm 80 83.3mm 10M
    AQS-505-35A15 3500K 24V DC 10W 432lm 80 83.3mm 10M
    AQS-505-40A15 4000K 24V DC 10W 440lm 80 83.3mm 10M
    AQS-505-45A15 4500K 24V DC 10W 445lm 80 83.3mm 10M
    AQS-505-50A15 5000K 24V DC 10W 430lm 80 83.3mm 10M
    AQS-505-65A15 5000K 24V DC 10W 442lm 80 83.3mm 10M

    AQS-510 Neon Flex

    IP68  -  24V DC
    Vertical bending  -  Emission Angle 120°
    3-year Aqualux Warranty
    16.5mm Wide x 16.5mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Cut Interval Max run (single Feed)
    AQS-510-RDA10 Red 24V DC 10W 109lm 80 83.3mm 10M
    AQS-510-GNA10 Green 24V DC 10W 338lm 80 83.3mm 10M
    AQS-510-BUA10 Blue 24V DC 10W 53lm 80 83.3mm 10M
    AQS-510-AMA10 Amber 24V DC 10W 110lm 80 83.3mm 10M
    AQS-510-22A10 2200K 24V DC 10W 358lm 80 83.3mm 10M
    AQS-510-27A10 2700K 24V DC 10W 459lm 80 83.3mm 10M
    AQS-510-30A10 3000K 24V DC 10W 450lm 80 83.3mm 10M
    AQS-510-35A10 3500K 24V DC 10W 414lm 80 83.3mm 10M
    AQS-510-40A10 4000K 24V DC 10W 460lm 80 83.3mm 10M
    AQS-510-45A10 4500K 24V DC 10W 484lm 80 83.3mm 10M
    AQS-510-50A10 5000K 24V DC 10W 540lm 80 83.3mm 10M
    AQS-510-65A10 6500K 24V DC 10W 521lm 80 83.3mm 10M
    AQS-510-Z1A13 RGB 24V DC 13W ???lm 80 83.3mm 10M
    AQS-510-Z3A17 RGB + 2700K 24V DC 17W ???lm 80 100mm 8M
    AQS-510-Z6A18 RGB + 2700K 24V DC 18W ???lm 80 100mm 8M

    AQF-C

    IP65  -  24V AC or 24V DC
    Commercial grade Festoon lighting
    3-year Aqualux Warranty
    95mm Wide x 41.5mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI Lamp spacing Max run (single Feed)
    AQF-C-025B Lamp dependant 24V Ac / DC Lamp dependant Lamp dependant Lamp dependant 25cm Lamp dependant
    AQF-C-050B Lamp dependant 24V Ac / DC Lamp dependant Lamp dependant Lamp dependant 50cm Lamp dependant
    AQF-C-100B Lamp dependant 24V Ac / DC Lamp dependant Lamp dependant Lamp dependant 100cm Lamp dependant

    AQF-GWW

    IP65  -  24V DC
    Commercial-grade Fairy lighting
    3-year Aqualux Warranty
    8.65mm Wide x 31.5mm High

    Code CCT Voltage Watts P/M Lumen P/M CRI LEDs P/M Max run (single Feed)
    AQF-GWW-5M 2200K 24V DC 2.16W ? ? 48 111M
    AQF-GWW-10M 2200K 24V DC 4.32W ? ? 96 55M
    AQF-GWW-20M 2200K 24V DC 8.46W ? ? 192 28M
