Neon Flex
AQS-510
IP68 Neon Flex
Introduction
AQS-510 is a high output top-view IP68 Neon Flex in Mono, RGB, RGBW and DMX options. Use for external facade illumination, pool copings, in-pavement channels and exterior wall grazing where substantial moisture and mechanical protection is required. As with all IP68 products, the ingress protection is determined by the quality of the cable joins and installation. NOTE: Please check datasheets for details.
Specifications
AQS-510-Mono / RGB / RGBW / DMX
24V DC
10W / 13W / 17W / 18W
IP68
Refer to Page 2 Chart of the Datasheet
2200K to 6500K - R - G - B - Amber / RGB / RGBW / 2700K - R - G - B
Constant Voltage (PWM) / DMX / DMX(RS485)
10m / 10m / 8m / 8m
20m / 20m / 16m / 16m
83.30mm / 83.30mm / 100mm / 100mm
Vertically
120mm
SMD3528 / SMD5050
144pcs / 72pcs / 60pcs / 70pcs
70,000 Hours L70@ 25°C, 50,000 Hours L70@ 50°C
Eco PVC
120°
-20° to +40°C
5° to +35°C
3 Year Aqualux Warranty
